John Deere 3.152

配件详情

John Deere 3.152 o'rings块


三百
系列
发动机与设备模型
三点一五二
从ESN 154766

o'rings块

孔：
3.86在98毫米

销Ø：
1.1878（+ / - 0001）= 30mm

块（M）：
r53240
r55100
r72967
t32339
Con Rod（M）：
t20007
r81410
活塞（M）：
ar87736
ar90550

应用

农业的
八百二十
一千零二十
八百三十
一千零三十
施工
三百
301A
300A
350A
300B
350B
三百零一
三百八十
1）
发动机O / H试剂盒
tok3591
（试剂盒内容点击）
2）
发动机的I / F试剂盒
tik3591
（试剂盒内容点击）
缸套活塞组件
tar71591
由：
a)
TT23481
b)
TAR70633
c)
tt23482
D）
tt32340
E）
TAR71617
f)
TR51112
Main Bearing
TRE27352
STD
tre27353
零点零一零
tre27360
零点零二零
TRE27368
零点零三零
Use 3
Thrust Bearing
TAT21139
STD
tat21132
零点零一零
tat21134
零点零二零
TAT21136
零点零三零
Use 1
Con Rod Bearing
TRE27348
STD
TRE27349
零点零一零
TRE27358
零点零二零
tre27364
零点零三零
使用3
1）
前密封
TAR67942
2）
Rear Seal
TRE44574
(1)
3)
曲轴
tat18031
4）
曲轴、齿轮
tt20094
5）
齿圈
tr114282
（142t）
1）
O / H垫
TRE38570
2）
气缸盖垫片修理包
TRE38848
3)
Head Gasket
TR98460
4）
Oil Pan Gasket
TR97341
5)
Rocker Cover Gsk
TR75729
6)
定时盖垫片
tt20273
7）
垫片调温器外壳
TT20219
1)
Bush, Con Rod
TT23471
x3
2）
螺栓，Con Rod
tr74194
X6
（4）
3)
Camshaft Kit
TRE55900
4）
Con Rod
tat18005
1）
泵，油
tre55343
2）
油冷却器
TRE31929
(3)
3)
Rocker Arm
TRE31973
4）
Rocker Shaft
TR54985
5)
Pump, Oil Tube
TR113752
6)
Oil Pump O'Ring
TR61871
1)
Lower Gear
TAT24252
2)
Lower Bushing
TT26321
3)
Upper Gear
TAT18009
4）
Upper Bushing
TT20034
5)
Cam. Follower
TT20073
x6
6)
Cam. 齿轮
TT20070
7)
Camshaft Kit
TRE55900
(5)

Valve Section

（点击图片放大阀图。）

阀，Intake
tr79623
STD
TR79628
零点零零三
TR79629
零点零一五
Valve, Exhaust
TR79624
STD
TR79625
零点零零三
TR79626
零点零一五
1)
Insert, Valve In
TR73064
STD
2）
Insert, Valve Ex
TR51734
STD
1)
Cap, Valve
TT20129
2）
Lock, Valve
TT20077
1)
Spring, Valve
TR26125
2）
Rotator, Valve
TRE11410
3)
O’ring, Valve
TR87627
1)
恒温器
TRE33705
180° F
(2)
2）
节温器盖
tt23620
3）
节温器盖葛兰素史克
tt20215
1）
Fuel Transfer Pump
TRE42211
2）
Fuel Pump Gasket
TR27285
Water Pump Repair Kit
Without Impeller
TRE19507
With Impeller
TRE62658
Water Pump Gasket
TT20242
TT20268

1)
Injector, Pencil
TAR89564
2）
Kit, Grommet
TMX504
3)
帽子
tat27622
tar85618
4）
洗衣机
TT29539
5)
Tube Nut
TR51937
Seal, Injector
TR60746
TR48000
