美国约翰迪尔3029T柴油发动机维修保养用配件

湖南英珀威机械有限公司专业的美国约翰迪尔3029T柴油发动机维修保养用配件销售维修保养服务代理商，服务热线：15580888444
产品咨询

详细描述

John Deere 3029T Liter Designated


300
 Series
Engine & Equipment Model
3029T
Liter Designated

Bore:
4.19 in 106.5 mm

Pin Ø:
1.6250 in (+/- .0002) = 41mm

Con Rod (m):
R80032
R58979
R113612
Piston (m):
RE48368

Applications

AGRICULTURAL
5500
DITCH WITCH
JT2321
Directional Boring System
SKID STEER
250
250 Series II
260
260 Series II
8875
1)
Engine O/H Kit
TOK3115
(Click for Kit Contents)
2)
Engine I/F Kit
TIK3115
(Click for Kit Contents)
Piston-Liner Kit
TRE33115
Consists of:
a)
TRE19278
b)
TRE66820
c)
TR124230
d)
TR116281
e)
TAR65507
f)
TR54114
Main Bearing
TRE27352
Std.
TRE27353
0.010
TRE27360
0.020
TRE27368
0.030
Use 3
Thrust Bearing
TAT21139
Std.
TAT21132
0.010
TAT21134
0.020
TAT21136
0.030
Use 1
Con Rod Bearing
TRE27348
Std.
TRE27349
0.010
TRE27358
0.020
TRE27364
0.030
Use 3
1)
Front Seal
TAR67942
2)
Rear Seal
TRE44574
3)
Crankshaft
TRE521348
(5)
4)
Crankshaft, Gear
TT20094
5)
Ring Gear
TR114282
(142T)
6)
Sleeve, Front
TR81989
7)
Packing, Sleeve
TH35244
1)
O/H Gasket Set
TRE501578
2)
Head Gasket Set
TRE38850
3)
Head Gasket
TR97356
4)
Oil Pan Gasket
TR97341
5)
Rocker Cover Gsk
TR75729
(2)
TR106796
(1)
1)
Bush, Con Rod
TR57451
x3
2)
Bolt, Con Rod
TR80033
x6
3)
Con Rod
TRE58347
4)
Kit, Piston Pin
TRE63913
x3
1)
Pump, Oil
TRE55343
2)
Oil Cooler
TRE61767
5)
Pump, Oil Tube
TR113752
6)
Cyl Hd Cap Screw
TR85363
x14
(4)
1)
Lower Gear
TAT24252
(3)
2)
Lower Bushing
TT26321
3)
Upper Gear
TAT18009
(3)
4)
Upper Bushing
TT20034
5)
Cam. Follower
TT20073
x6
6)
Cam. Gear
TT20070
(3)
7)
Camshaft Kit
TRE55900
(9)
8)
Camshaft
TR106957
(9)

Valve Section

(Click image to zoom the valve diagram.)

Valve, Intake
TR98062
Std.
TR97490
0.015
Valve, Exhaust
TR90692
Std.
TR97492
0.015
1)
Insert, Valve In
TR98063
Std.
TR98335
O/S
2)
Insert, Valve Ex
TR51734
Std.
TR93910
O/S
1)
Seal, Valve
TRE31617
2)
Lock, Valve
TR91889
1)
Spring, Valve
TR26125
2)
Rotator, Valve
TRE60005
1)
Thermostat
TRE64354
180° F
2)
Thermostat Cover
TT23620
3)
Water Temp Sensor
TRE51774
(8)
Fuel Transfer Pump
TRE42211
Water Pump Repair Kit
Without Impeller
TRE19507
With Impeller
TRE62658
Water Pump
TAR97708U
(6)
TRE60489
(7)
TAR92641
(8)
1)
Seal, Injector
TR60746
TR48000
2)
Injector, Pencil
TRE38087
3)
KIT, GROMMET
TMX504

(1) Not included in Gasket Set. Used in Saran Engines (Order separately).

(2) Reusable.

(3) Helicoidal Gears.

(4) Replace all R78558 Cap Screws with Flanged Head Cap Screw TR85363.

(5) Kit contains TT20094 helical gear to convert to a TRE50979 Crankshaft.

(6) (m) R73604.

(7) (m) R100812, (m) R127337, (m) R127918, (m) R55164.

(8) Check your application for proper usage.

(9) Camshaft has a 40 mm wide front bearing journal and made for a rear press in tachometer drive, it will replace early camshafts with narrower front bearing journal without any issue. Replaces camshafts marked T20015, T20016, R79643, R106957 and RE522311.
