John Deere 3029D Liter Designated


300
 Series
Engine & Equipment Model
3029D
Liter Designated

Bore:
4.19 in 106.5 mm

Pin Ø:
1.3750 in (+/- .0002) = 35mm

Con Rod (m):
R51727
R80034
Piston (m):
RE30250

Applications

AGRICULTURAL
5200
5300
5400
SKID STEER
240
240 Series II
1)
Engine O/H Kit
TRE47653
(Click for Kit Contents)
2)
Engine I/F Kit
TIK47653
(Click for Kit Contents)
Piston-Liner Kit
TRE30250
Consists of:
a)
TRE19282
b)
TRE66820
c)
TR125754
d)
TR116281
e)
TAR65507
f)
TM41029
Main Bearing
TRE27352
Std.
TRE27353
0.010
TRE27360
0.020
TRE27368
0.030
Use 3
Thrust Bearing
TAT21139
Std.
TAT21132
0.010
TAT21134
0.020
TAT21136
0.030
Use 1
Con Rod Bearing
TRE27348
Std.
TRE27349
0.010
TRE27358
0.020
TRE27364
0.030
Use 3
1)
Front Seal
TAR67942
2)
Rear Seal
TRE44574
3)
Crankshaft
TRE521348
(5)
4)
Crankshaft, Gear
TT20094
(3)
5)
Ring Gear
TR114282
(142T)
6)
Sleeve, Front
TR81989
7)
Packing, Sleeve
TH35244
1)
O/H Gasket Set
TRE501578
2)
Head Gasket Set
TRE38850
3)
Head Gasket
TR97356
4)
Oil Pan Gasket
TR97341
5)
Rocker Cover Gsk
TR75729
(2)
TR106796
(1)
1)
Bush, Con Rod
TR55647
x3
2)
Bolt, Con Rod
TR80033
x6
3)
Camshaft Kit
TRE55900
4)
Con Rod
TRE16495
1)
Pump, Oil
TRE55343
2)
Oil Cooler
TRE61767
5)
Pump, Oil Tube
TR113752
4)
Cyl Hd Cap Screw
TR85363
x14
(4)
1)
Lower Gear
TAT24252
(3)
2)
Lower Bushing
TT26321
3)
Upper Gear
TAT18009
(3)
4)
Upper Bushing
TT20034
5)
Cam. Follower
TT20073
x6
6)
Cam. Gear
TT20070
(3)
7)
Camshaft Kit
TRE55900
(9)
8)
Camshaft
TR106957
(9)

Valve Section

(Click image to zoom the valve diagram.)

Valve, Intake
TR98062
Std.
TR97490
0.015
Valve, Exhaust
TR90692
Std.
TR97492
0.015
1)
Insert, Valve In
TR98063
Std.
TR98335
O/S
2)
Insert, Valve Ex
TR51734
Std.
TR93910
O/S
1)
Seal, Valve
TRE31617
2)
Lock, Valve
TR91889
1)
Spring, Valve
TR26125
2)
Rotator, Valve
TRE60005
1)
Thermostat
TRE64354
180° F
2)
Thermostat Cover
TT23620
3)
Water Temp Sensor
TRE51774
(8)
Fuel Transfer Pump
TRE42211
Water Pump Repair Kit
Without Impeller
TRE19507
With Impeller
TRE62658
Water Pump
TAR97708U
(6)
TRE60489
(7)
TAR92641
(8)
1)
Seal, Injector
TR60746
TR48000
2)
Injector, Pencil
TRE36936
3)
KIT, GROMMET
TMX504

(1) Not  included in Gasket Set. Used in Saran Engines (Order Separately).

(2) Reusable.

(3) Helicoidal Gears.

(4) Replace all R78558 Cap Screws with Flanged Head Cap Screw TR85363.

(5) Kit contains TT20094 helical gear to convert to a TRE50979 Crankshaft.

(6) (m) R73604.

(7) m) R100812, (m) R127337, (m) R127918, (m) R55164.

(8) Check your application for proper usage.

(9) Camshaft has a 40 mm wide front bearing journal and made for a rear press in tachometer drive, it will replace early camshafts with narrower front bearing journal without any issue. Replaces camshafts marked T20015, T20016, R79643, R106957 and RE522311.
