John Deere 3.179T


300
 Series
Engine & Equipment Model
3.179T

Bore:
4.19 in 106.5 mm

Pin Ø:
1.6250 in (+/- .0002) = 41mm

Con Rod (m):
R80032
Piston (m):
RE22678

Applications

AGRICULTURAL
2355 NCS
2355 NTSS
DITCH WITCH
JT2321
Directional Boring System
1)
Engine O/H Kit
TOK3115
(Click for Kit Contents)
2)
Engine I/F Kit
TIK3115
(Click for Kit Contents)
Piston-Liner Kit
TRE33115
Consists of:
a)
TRE19278
b)
TRE66820
c)
TR124230
d)
TR116281
e)
TAR65507
f)
TR54114
Main Bearing
TRE27352
Std.
TRE27353
0.010
TRE27360
0.020
TRE27368
0.030
Use 3
Thrust Bearing
TAT21139
Std.
TAT21132
0.010
TAT21134
0.020
TAT21136
0.030
Use 1
Con Rod Bearing
TRE27348
Std.
TRE27349
0.010
TRE27358
0.020
TRE27364
0.030
Use 3
1)
Front Seal
TAR67942
2)
Rear Seal
TRE44574
3)
Crankshaft
TAT18031
(3)
4)
Crankshaft, Gear
TT20094
5)
Ring Gear
TR114282
(142T)
6)
Sleeve, Front
TR81989
7)
Packing, Sleeve
TH35244
1)
O/H Gasket Set
TRE501578
2)
Head Gasket Set
TRE38850
3)
Head Gasket
TR97356
4)
Oil Pan Gasket
TR97341
5)
Rocker Cover Gsk
TR75729
1)
Bush, Con Rod
TR57451
x3
2)
Bolt, Con Rod
TR80033
x6
3)
Con Rod
TRE58347
4)
Kit, Piston Pin
TRE63913
x3
1)
Pump, Oil
TRE55343
2)
Oil Cooler
TRE31929
(4)
3)
Rocker Arm
TRE31973
4)
Rocker Shaft
TR54985
5)
Pump, Oil Tube
TR113752
6)
Cyl Hd Cap Screw
TR85363
x14
(2)
1)
Lower Gear
TAT24252
2)
Lower Bushing
TT26321
3)
Upper Gear
TAT18009
4)
Upper Bushing
TT20034
5)
Cam. Follower
TT20073
x6
6)
Cam. Gear
TT20070
7)
Camshaft Kit
TRE55900
(8)
8)
Camshaft
TR106957
(8)

Valve Section

(Click image to zoom the valve diagram.)

Valve, Intake
TR83071
Std.
TR89223
0.003
TR89224
0.015
Valve, Exhaust
TR79624
Std.
TR79625
0.003
TR79626
0.015
1)
Insert, Valve In
TR73064
Std.
2)
Insert, Valve Ex
TR51734
Std.
1)
Cap, Valve
TT20129
2)
Lock, Valve
TT20077
1)
Spring, Valve
TR26125
2)
Rotator, Valve
TRE11410
3)
O’ring, Valve
TR87627
1)
Thermostat
TRE33705
180° F
(1)
2)
Thermostat Cover
TT23620
Fuel Transfer Pump
TRE42211
Water Pump Repair Kit
Without Impeller
TRE19507
With Impeller
TRE62658
Water Pump
TAR97708U
(5)
TRE60489
(6)
TAR92641
(7)
1)
Seal, Injector
TR60746
TR48000
2)
Injector, Pencil
TRE37503
3)
KIT, GROMMET
TMX504
4)
Glow Plug
TRE502079

(1) Do not use with Housing (m) R54096, R70741, R74549. For Saran Repower Engines use TRE64354.

(2) Replace all R78558 Cap Screws with Flanged Head Cap Screw TR85363.

(3) Crankshaft (m) T23516 (36 mm / 1.37” Snout.) This engine may use TRE50979 (60 mm / 2.36” Snout) (m) R91834.

(4) Use on engines ESN 794193, after this ESN use TRE61767.

(5) (m) R73604.

(6) (m) R100812, (m) R127337, (m) R127918, (m) R55164.

(7) Check your application for proper usage.

(8) Camshaft has a 40 mm wide front bearing journal and made for a rear press in tachometer drive, it will replace early camshafts with narrower front bearing journal without any issue. Replaces camshafts marked T20015, T20016, R79643, R106957 and RE522311.
